| PTO Drive Standard specification | 540 RPM 1'' 3/8 Z6 |
| $0.00 |
| PTO Drive Option specification | 1000 RPM 1'' 3/8 Z21 |
| $0.00 |
| 2 speed Gear Box | Optional |
| $0.00 |
| 2 speed Gear Box and ratio | D732, 1;1,5 540RPM |
| $0.00 |
| PTO HP Requirement (Low Speed) | 60/65/70/75 |
| $0.00 |
| PTO HP Requirement (High Speed) | 85/90/95/100 |
| $0.00 |
| Auger RPM – Low Speed | 27 RPM |
| $0.00 |
| Auger RPM – Standard High speed | 41 RPM |
| $0.00 |
| Standard planetary model and ratio configuration | 2002 @13,4 |
| $0.00 |
| Optionnal Planetary | N/A |
| $0.00 |
| Floor Thickness (AR400 grade) | 5/8’’ |
| $0.00 |
| Sidewall Thickness (AR235 grade) | 1/4‘’ |
| $0.00 |
| Flighting Thickness (AR400 grade) | 5/8’’ |
| $0.00 |
| Standard knives per auger | 10 |
| $0.00 |
| Drive line security | Shear bolt |
| $0.00 |
| Hydraulic flow requirement | 10-15 US gal/min 37-56 L/min |
| $0.00 |
| Hydraulic pressure | 160-200 bars (2300 - 2900 psi) |
| $0.00 |
| Load cell | 3 |
| $0.00 |
| Scale system | DG500 (standard) Smart Control (optional) |
| $0.00 |
| Machine Weight | 4000kg (8800 lb) |
| $0.00 |
| Utility load capacity | 5010kg (11 020 lb) |
| $0.00 |
| Maximum speed | 40 km/h (25 mph) |
| $0.00 |
| Axle Standard specification | Single |
| $0.00 |
| Wheels Standard specifications | 15,0/55-17 26 PLY |
| $0.00 |
| Axle - option | N/A |
| $0.00 |
| Wheels Option specifications | N/A |
| $0.00 |
| Wheels pressure specifications | 7,1 bar (103 psi) |
| $0.00 |
| Length (A) | 18' 5" (5,61 m) |
| $0.00 |
| Height (B) no extension | 8' 10" (2,69 m) |
| $0.00 |
| 6" capacity extension | 9' 4" (2,84 m) |
| $0.00 |
| 12" capacity extension | 9' 10" (3,00 m) |
| $0.00 |
| 18" capacity extension | 10'4" (3,14 m) |
| $0.00 |
| Hay retention ring (additionnal height) | 0'' (0,00 m) |
| $0.00 |
| Width without option | 8' 1" (2,46 m) |
| $0.00 |
| Incline conveyor 3ft (0,9 m) transport mode | 9' 3" (2,82 m) |
| $0.00 |
| Incline conveyor 3ft (0,9 m) working mode | 10' 11" (3,33 m) |
| $0.00 |
| Incline conveyor 4ft ( 1,2 m) transport mode | 9' 3" (2,82 m) |
| $0.00 |
| Incline conveyor 4ft ( 1,2 m) working mode | 11' 6" (3,53 m) |
| $0.00 |
| Incline conveyor 5ft ( 1,5 m) transport mode | 9' 3" (2,82 m) |
| $0.00 |
| Incline conveyor 5ft ( 1,5 m) working mode | 12' 7" (3,85 m) |
| $0.00 |
| Incline conveyor 3ft (0,9 m) | 3' 2" (0,97 m) |
| $0.00 |
| Incline conveyor 4ft ( 1,2 m) | 3' 9" (1,16 m) |
| $0.00 |
| Incline conveyor 5ft ( 1,5 m) | 4' 10" (1,48 m) |
| $0.00 |
| Floor(ST) / Belt(FD) to ground | 32" (0,81 m) |
| $0.00 |
| Incline conveyor 3ft (0,9 m) | 3' 5" (1,05 m) |
| $0.00 |
| Incline conveyor 4ft ( 1,2 m) | 3' 11" (1,20 m) |
| $0.00 |
| Incline conveyor 5ft ( 1,5 m) | 4' 9" (1,45 m) |
| $0.00 |
| Outside width of the wheels (F) | 6' 9"( 2,06 m) |
| $0.00 |
| Capacity (no capacity extension) | 380 ft3 (10,8 m3) |
| $0.00 |
| 6" capacity extension | 416 ft3 (11,8 m3) |
| $0.00 |
| 12" capacity extension | 453 ft3 (12,8 m3) |
| $0.00 |
| 18" capacity extension | 490 ft3 (13,8 m3) |
| $0.00 |
| Number of Auger | 1 |
| $0.00 |
